02,Apr,2025
What is the main purpose of a current transformer? + Read More
| Measuring Range | |
| Current Meas.Range | 100mA-5.5A; 10/5A-9995/5A(...x5) |
| Voltage Meas.Range | 10~500V AC |
| Frequency Meas.Range | 1~400Hz |
| Operating Voltage(Un) | 150V-270VACor 110VAC |
| Operating Frequency | 50/60Hz. |
| Operating Power | <4VA |
| Operating Temperature | -20℃-55℃ |
| Current Measurement Range | 100mA~5.5AAC |
| CurrentTransformer | 1015A~9995/5A(...×5) |
| Measurement Precision | ±1% |
| Display | 3×3 digit 14mm Display 1 led |
| ConnectionType | Plug-in Terminal |
| Cable Diameter | 1.5mm² |
| Weight | <310gr. |
| Panel Hole Sizes | 91×91mm |
| Mounting | Front panei mounted |
| Protection Class | IP41 |
| OperatingAltitude | <2000 meter |
